CRS XL - Blower Replacement Parts
CRS XL Blower Replacement Parts
We maintain a complete selection of Blower Replacement Parts for your CRS XL. For easy ordering click on the yellow key number bubble in the drawing below. A small window will open where you can change the quantity of the part you’re ordering and add it right to your cart from there. Or you can scroll farther down the page and order from the more detailed list of parts.
Our impellers are specifically designed to only be used with our Cyclone Rakes. They are designed for an engine with a 1" diameter, keyed shaft with a 3" reveal. Do not order a larger impeller than what is offered for your specific Cyclone Rake as it will not fit and function properly.
If you are unsure of the part you need, or don’t see it listed here, give our Product Technicians a call and we’ll get you back up and running.
| Key # | Part # | Product Name | QTY | Price | |
|---|---|---|---|---|---|
| 233 | 01-04-013 | Safety glasses & ear plug set |
$8.00
| ||
| 96 | 01-01-201 | 5/16-18 x 3/4 bolt |
$2.00
| ||
| 022 | 02-03-023 | 5-Blade Green Impeller w/hardware kit |
$199.00
| ||
| 003e | 05-02-077 | Exit Chute Complete with Latches- XL & Z-10 (Yellow) |
$135.00
| ||
| 037b | 05-01-173 | 10-24 X 3/4" Phillips Round Head Screw (XL & Z-10 Only) |
$0.50
| ||
| 162 | 09-02-055 | Square plastic plug for motor frame-Set of 4 |
$5.50
| ||
| 164 | 05-02-003 | Motor Frame with square plugs |
$49.50
| ||
| 172a | 01-02-681 | Engine Clamp Handle with Rubber Washers (Set of 2) |
$19.90
| ||
| 269 | 01-01-563 | 10-24 x 1/2" Liner Screw |
$0.75
|
